SIRIUS
®
TECHNICAL REFERENCE MANUAL
4.2.1. Modular solution
A single SIRIUS® slice can have up to 8 measurement modules.
Each measurement module has typically one analog channel. Some modules also have an optional
counter channel (e.g. ACC+). HD modules have 2 analog channels.
SIRIUSi-8xSTGM+
We offer several standard chassis with predefined modules, but you can also choose a customized slice
with any combination of the SIRIUS® measurement modules.
You can choose between 2 different data-transfer options:
USB
EtherCA
Hint
You can use your SIRIUS® slices independently or combine them to a single fully-synchronized
multi-channel measurement system with the clever click mechanism.
SIRIUS
®
V20-1 33 / 336

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the DEWESOFT SIRIUS Series and is the answer not in the manual?

DEWESOFT SIRIUS Series Specifications

General IconGeneral
CategoryData Loggers
ManufacturerDEWESOFT
SeriesSIRIUS
Resolution24-bit
InterfaceUSB, EtherCAT
SoftwareDEWESoft X
ChannelsExpandable
Sampling RateUp to 200 kS/s per channel
Input TypesVoltage, Current, IEPE, Strain, Thermocouple, RTD, Resistance, Digital, Counter
Input Voltage Range±10 V, ±200 V
IsolationChannel-to-channel and channel-to-ground
ConnectivityEthernet, USB
Operating Temperature-10 °C to +50 °C
Storage Temperature-20 °C to +70 °C
Power Supply10 to 30 V DC
DimensionsVaries depending on module configuration
WeightVaries depending on module configuration
Analog InputsYes, depending on module configuration
