4.10.3. SIRIUS-R4: Specification 
Computer 
Processor 
Intel® Core™ i7; 2x 2.6 GHz base, 3.4 GHz max; 4 threads 
Memory 
8 GB (optional up to 32 GB) 
Storage 
Non-removable M2 250 GB (500 GB, 1 TB as option) 
Interfaces and options 
USB Front 
4x USB 3.0 
Ethernet 
2x GLAN (RJ45) 2x front, 1x WLAN (RP-SMA Female Jack) 
EtherCAT® 
1x EtherCAT® 100 Mbps Full Duplex, 8-pin LEMO female 
Synchronisation 
2x SIRIUS® SYNC 
Video 
1x HDMI 
GPS (option) 
10 Hz or 100 Hz or 100 Hz + RTK 
GPS display (option) 
External on DSUB-9 female connector + remote power on 
Power 
Power supply 
9 - 36 V DC 
Power consumption 
Typ. 30 W (Max. 35 W) 
(excl. SIRIUS® slices) 
Power out & EtherCAT® Power out 
Type 
Switched input supply on 2-pin LEMO female 
& EtherCAT® connector, 8-pin LEMO female 
Maximum power 
60 W (combined Power out & EtherCAT® Power out) 
Output Voltage 
12 - 36 V DC 
R4rt optional EtherCAT® slave port 
Minimum delay (analog input to EtherCAT® bus) 
70 µs 
Minimum EtherCAT® cycle time 
100 µs 
Environmental 
Operating Temperature 
-10 to 50°C 
Storage Temperature 
-40 to 85°C 
Humidity 
95 % RH non condensing @ 50 °C 
IP rating 
IP20 
Shock & Vibration 
Vibration sweep sinus (EN 60068-2-6:2008)\ 
Vibration random (EN 60721-3-2: 1997 - Class 2M2) 
Shock (EN 60068-2-27:2009) 
MIL-STD-810D 
Physical 
Dimensions 
276 x 251 x 150 mm 
Weight 
3.2 kg (excl. SIRIUS® slices) 
 
SIRIUS
®
V20-1 79 / 336  

DEWESOFT SIRIUS Series Specifications

General

Category	Data Loggers
Manufacturer	DEWESOFT
Series	SIRIUS
Resolution	24-bit
Interface	USB, EtherCAT
Software	DEWESoft X
Channels	Expandable
Sampling Rate	Up to 200 kS/s per channel
Input Types	Voltage, Current, IEPE, Strain, Thermocouple, RTD, Resistance, Digital, Counter
Input Voltage Range	±10 V, ±200 V
Isolation	Channel-to-channel and channel-to-ground
Connectivity	Ethernet, USB
Operating Temperature	-10 °C to +50 °C
Storage Temperature	-20 °C to +70 °C
Power Supply	10 to 30 V DC
Dimensions	Varies depending on module configuration
Weight	Varies depending on module configuration
Analog Inputs	Yes, depending on module configuration
