SIRIUS
®
TECHNICAL REFERENCE MANUAL
4.5.4. SIRIUS-SBOXfe: Front side
The SIRIUS-SBOXfe version is an SBOX with EtherCAT® interface. It is available for the Modular Solution.
It includes the Intel® Core i7 high speed CPU which is the most powerful processor of the Intel®
Core processor family for fanless operation.
SIRIUS-SBOXfe Front side
Name
Description
PWR LED light
Green when Power is available and switch on
PWR switch
Power On rocker switch
SSD
Removable Solid State Disk
LAN
1x GLAN Ethernet, RJ45 connector
USB 3.0
4x USB 3.0 connector
SIRIUS
®
V20-1 59 / 336
