DEWESOFT SIRIUS Series User Manual

/
SIRIUS
® 
TECHNICAL REFERENCE MANUAL 


4.9.1. SIRIUS-R3: Specifications 
Computer 
Processor 
Intel® Core™ i7-8700; 6 cores, 12 threads; 3.2 GHz base, 4.6 GHz max 
Memory 
8 GB (optional up to 128 GB) 
Storage 
2x 500 GB removable SATA SSD 
Option: 1 TB removable SATA SSD 
Motherboard 
ATX Form Factor; 30.5 cm x 24.5 cm 
Intel® Z390 Express Chipset 
TPM available upon request ??? 
Interfaces and options 
USB Back 
1x USB Type-C™, 2x USB 3.1 Gen 2, 3x USB 3.1 Gen 1, 4x USB 2.0/1.1 
USB Front 
2x USB 3.1 Gen 1 
Ethernet 
1x GLAN (RJ-45) 
Synchronisation 
2x SIRIUS® SYNC on back 
Video 
1x HDMI 
Audio 
5x audio jacks, 1x optical S/PDIF Out 
DS-IRIG-CLOCK 
option, BNC input on back 
Power 
Power supply 
115 - 230 VACrms, 50 - 60 Hz 
Power consumption 
Max. 350 W 
Environmental 
Operating Temperature 
0 to 50°C 
Storage Temperature 
-20 to 75°C 
Humidity 
10 - 90 % RH non condensing 
IP rating 
IP20 
Shock & Vibration 
Vibration random (EN 60721-3-2: 1997 - Class 2M2) 
Physical 
Dimensions 
544 x 483 x 177 mm 
Weight 
16.2 kg (excl. SIRIUS® slices) 
 
SIRIUS
®
V20-1 74 / 336  

DEWESOFT SIRIUS Series Specifications

General

Category	Data Loggers
Manufacturer	DEWESOFT
Series	SIRIUS
Resolution	24-bit
Interface	USB, EtherCAT
Software	DEWESoft X
Channels	Expandable
Sampling Rate	Up to 200 kS/s per channel
Input Types	Voltage, Current, IEPE, Strain, Thermocouple, RTD, Resistance, Digital, Counter
Input Voltage Range	±10 V, ±200 V
Isolation	Channel-to-channel and channel-to-ground
Connectivity	Ethernet, USB
Operating Temperature	-10 °C to +50 °C
Storage Temperature	-20 °C to +70 °C
Power Supply	10 to 30 V DC
Dimensions	Varies depending on module configuration
Weight	Varies depending on module configuration
Analog Inputs	Yes, depending on module configuration
