DEWESOFT SIRIUS Series

/
SIRIUS
® 
TECHNICAL REFERENCE MANUAL 


100 g @ 4 ms 50x, half sine, all axis 
Vibration 
Random: 
Profile breakpoints: 
24 Hz - 0.023 g²/Hz 
60 Hz - 0.28 g²/Hz 
100 Hz - 0.28 g²/Hz 
240 Hz - 0.056 g²/Hz 
2 kHz - 0.056 g²/Hz 
Profile RMS / Peak = 11.5 g / 34.5 g (up to 15 / 45 g with absorbers) 
6 hrs in each axis, 18 hrs total 
Physical 
Dimensions 
282 x 135 x 70 mm 
282 x 135 x 85 mm 
282 x 135 x 70 mm 
Weight 
2.07 kg 
4.56 lbs 
2.73 kg 
6.02 lbs 
2.07 kg 
4.56 lbs 

Important 
See corresponding specifications of amplifier modules for more details. 

 
SIRIUS
®
V20-1 144 / 336  
