DEWESOFT SIRIUS Series User Manual

/
SIRIUS
® 
TECHNICAL REFERENCE MANUAL 


● Added chapter for “R8D Mounting” 
1.4.2 
13.11.2015 
● General Specifications: Updated Humidity, added Acquisition rate – 
Time base accuracy 
● HVv2, HS‐HV: updated Input Impedance 
● Corrected description of Illustration in 5.21.2 HS-STG+ (Counter) L1B7f 
1.4.3 
02.03.2016 
● The Accessories chapter has been moved to a separate document 
(Accessories & Sensors) 
● Corrected article number of sync mating connector 
1.4.4 
09.03.2016 
● Replaced R2D with R2DB 
● Corrected the Power connector types 
● Corrected image of SBOXf backside-connectors 
● Removed 20Hz GPS option 
● Removed old documentation history entries (pre 1.3.0) from this 
table 
1.5.0 
09.03.2017 
● Added R8DB, R2D, SBOXre 
● changes: SBOX2→SBOXe, FLASH120→FLASH250, 
SIRIUSf-SBOX→SBOXfe, Single slice→Modular solution, 
Mulit‐slice→Boxed Solution 
● Updated specifications of all SBOXes 
● Updated specifications to HS‐LVv2 and HS_HVv2, HD-STGS 
(dynamic Range) 
● Counter modules: 
○ added chapter “General Counter Specifications” and 
clarification of the GND connection 
○ updated images 
● Added “R2DB Power-Out Specifications”, pinning table for 5.13.5 STG 
DSUB‐9, description for “Module” in chapter 5.2 Technology 
overview, 
● table with GPS specifications, MIL‐STD‐810D to Specifications, 
chapter “HS-STG: Sensor connection” 
● Added Mating Connector info to STG‐L2B7f, STG‐L2B10f and 
HD-STGS L1B10f 
● Update STGM to STGMv3 (Excitation Voltage: Predefined levels) 
● Updated STGv2 to STGv3: 
○ Updated Typ. CMR 
○ Max. common mode voltage 
● Updated ACC to ACCv2 (IEPE mode Excitation) 
○ Updated: Offset drift, Channel cross talk, Input coupling, 
Input Impedance 
● Updated HS-LV Input Impedance 
● HD-LV: added max. common mode voltage 
● HD-STGS: Max. common mode voltage 
● Corrected ADC link in specs of: HS-HV, HS-LV, HS-STG 
● HS-STG: update: offset drift, Max. common mode voltage, Offset 
accuracy after Balance Amplifier, Input accuracy 
SIRIUS
®
V20-1 335 / 336  

DEWESOFT SIRIUS Series Specifications

General

Category	Data Loggers
Manufacturer	DEWESOFT
Series	SIRIUS
Resolution	24-bit
Interface	USB, EtherCAT
Software	DEWESoft X
Channels	Expandable
Sampling Rate	Up to 200 kS/s per channel
Input Types	Voltage, Current, IEPE, Strain, Thermocouple, RTD, Resistance, Digital, Counter
Input Voltage Range	±10 V, ±200 V
Isolation	Channel-to-channel and channel-to-ground
Connectivity	Ethernet, USB
Operating Temperature	-10 °C to +50 °C
Storage Temperature	-20 °C to +70 °C
Power Supply	10 to 30 V DC
Dimensions	Varies depending on module configuration
Weight	Varies depending on module configuration
Analog Inputs	Yes, depending on module configuration
