On the front side of the SBOXre you can find these connectors: 
Name 
Description 
LAN 
1 (SBOXre) or 2 Ethernet (SBOXre-2GLAN) 1 Gbps, RJ45 connector 
WLAN ANT 
RP-SMA Female WLAN antenna: WiFi 802.11 b/g/n (not for SBOXre-2GLAN) 
DVI 
DVI Video out (VGA and HDMI compatible) 
GPS ANT 
SMA Female GPS antenna 
SSD 
Removable Solid State Drive 
EtherCAT 
8-pin LEMO female connector 
PWR Led light 
Green when Power is available and switched on 
PWR switch 
To switch the SBOX on/off. 
GPS 
DSUB-9 female GPS connector 
PWR OUT 
2-pin LEMO female connector 
SYNC 
2x 4-pin LEMO male sync connector 
USB 3.0 
4x USB 3.0 
POWER 
Power in 3-pin LEMO male connector 
GND 
Protective Ground banana plug and M4 insert 

 
SIRIUS
®
V20-1 87 / 336  

DEWESOFT SIRIUS Series Specifications

General

Category	Data Loggers
Manufacturer	DEWESOFT
Series	SIRIUS
Resolution	24-bit
Interface	USB, EtherCAT
Software	DEWESoft X
Channels	Expandable
Sampling Rate	Up to 200 kS/s per channel
Input Types	Voltage, Current, IEPE, Strain, Thermocouple, RTD, Resistance, Digital, Counter
Input Voltage Range	±10 V, ±200 V
Isolation	Channel-to-channel and channel-to-ground
Connectivity	Ethernet, USB
Operating Temperature	-10 °C to +50 °C
Storage Temperature	-20 °C to +70 °C
Power Supply	10 to 30 V DC
Dimensions	Varies depending on module configuration
Weight	Varies depending on module configuration
Analog Inputs	Yes, depending on module configuration
