D-Show Guide132
Control Ranges for Built-In Parametric EQ (All Modes)
Main Unit Fader Banks and Graphic EQ Frequency Bands
Table 18. Control ranges for built-in parametric EQ
Band Control Range (Digital) Defaults (Digital) Range (Analog) Defaults (Analog)
High
(Bell/Shelf)
Frequency 20 Hz to 20 kHz 10 kHz 2 kHz to 20 kHz 6 kHz
Gain ±18 dB 0 dB ±15 dB 0 dB
Q/Bandwidth 10 to 0.1 1.0 Shelf only none
High-Mid Frequency 20 Hz to 20 kHz 5 kHz 400 Hz to 8 kHz 2 kHz
Gain ±18 dB 0 dB ±15 dB 0 dB
Q/Bandwidth 10 to 0.1 1.0 0.1 to 2.0 octaves 0.2
Low-Mid Frequency 20 Hz to 20 kHz 1 kHz 100 Hz to 2 kHz 450 Hz
Gain ±18 dB 0 dB ±15 dB 0 dB
Q/Bandwidth 10 to 0.1 1.0 0.1 to 2.0 octaves 0.2
Low
(Bell/Shelf)
Frequency 20 Hz to 20 kHz 200 Hz 30 Hz to 200 Hz 80 Hz
Gain ±18 dB 0 dB ±15 dB 0 dB
Q/Bandwidth 10 to 0.5 1.0 Shelf only none
Main Unit Fader Banks and Graphic EQ Frequency Bands
Main Unit
Fader
Number
17 18 19 20 21 22 23 24
Bank 1 20 Hz 25 Hz 31.5 Hz 40 Hz 50 Hz 63 Hz 80 Hz 100 Hz
Bank 2 125 Hz 160 Hz 200 Hz 250 Hz 315 Hz 400 Hz 500 Hz 630 Hz
Bank 3 800 Hz 1000 Hz 1.25 kHz 1.6 kHz 2 kHz 2.5 kHz 3.15 kHz 4 kHz
Bank 4 5 kHz 6.3 kHz 8 kHz 10 kHz 12.5 kHz 16 kHz 20 kHz Output Level
