DigiDesign D-show User Manual

Chapter 29: FOH Rack Reference 215
Connector Pinouts
Not connected:
AA, DD, FF, z, x, w, v, u, t, e, L, g
FOH Link cable VGA BUNDLE pinouts
P1 VGA BUNDLE P2
U RED DATA U
A GREEN DATA A
T BLUE DATA T
VID V
B RED GND B
S GREEN GND S
n BLUE GND n
W GND W
CID C
mID m
p HSYNC p
X VSYNC X
kVGA SHIELD k
FOH Link cable RACK BUNDLE pinouts
P1 RACK BUNDLE P2
HH RACK PSU HH
BB RACK GND BB
CC RACK SHD CC
DD SPR 1 DD
GG SPR 2 GG
FOH Link cable TALKBACK BUNDLE pinouts
P1 TB BUNDLE P2
R TB P R
j TB N j
y TB GND y
P TB SHEILD P
FOH Link cable HEADPHONE BUNDLE pinouts
P1 HP BUNDLE P2
N HP L N
i HP R i
h HP GND h
M HP SHEILD M
FOH Link cable CAN BUNDLE pinouts
P1 CAN BUNDLE P2
Y CAN 1 H Y
r CAN 1 L r
Z CAN 2 H Z
s CAN 2 L s
a CAN 3 H a
b CAN 3 L b
E CAN 4 H E
F CAN 4 L F
D CAN CS D
FOH Link cable USB BUNDLE pinouts
P1 USB BUNDLE P2
K USB 5+ K
J USB GND J
H USB D+ H
d USB D– d
G USB SHIELD G
f USB +5 f
c USB GND c
