Chapter 6: Options 43
Input Settings
With the HDx TDM Record/Playback Option, you can replace
Stage Rack inputs with fixed HDx card outputs. On systems
with 2 Stage Racks and 2 HDx cards, you can replace the in-
puts from each Stage Rack independently.
Main Bus Settings
The Main Bus Settings let you configure the Main mix bus. See
“Configuring the Main Busses” on page 62.
L–R plus Mono
This default setting provides a stereo bus, plus one mono bus.
L–C–R
This setting enables L–C–R mode, which lets you mix in
“3-across-the-front” mode.
To change the Main Bus configuration:
1 Put D-Show in Config mode.
2 Go to the Options page and click the System Config tab.
3 Click Edit.
4 Click to choose a Main Bus mode.
5 Click Apply. D-Show restarts.
Bus Configuration Settings
The Bus Configuration Settings let you choose the D-Show
Aux and Group busses configuration. See “Configuring Aux,
Group, and Variable Group Busses” on page 62.
To change the Aux/Group/Variable Group Bus Configuration:
1 Put D-Show in Config mode.
2 Click the Edit button on-screen.
3 Click to select a Bus Configuration option.
4 Click Apply. D-Show restarts.
Input source selectors in the System Config page
See the HDx TDM Record/Playback Option Guide.
Main Busses options in the System Config page
Changing the Main Bus mode will restart the D-Show soft-
ware and may interrupt audio.
Bus Configuration in Config/Edit mode
