C106 - NATURAL (HEADLAMP/DASH SIDE)
CAV CIRCUIT
1 B4 18LG (ABS)
2 B3 18LG/DB (ABS)
3 B2 18YL (ABS)
4 B1 18YL/DB (ABS)
5 K106 18WT/DG
6 K107 18OR/RD
7 F18 20LG/BK
8 Z1 18BK (EXCEPT BUILT-UP-EXPORT)
8 L95 18DG/YL (BUILT-UP-EXPORT)
9 T44 20YL
10 T5 20LG/RD
C107 - LT. GRAY (HEADLAMP/DASH SIDE)
CAV CIRCUIT
1 K399 18BR/GY
2 L1 20VT/BK
3 F20 20WT
4 T1 20LG/BK
5 T3 20VT
6 T42 20VT/WT
7 T41 20BK/WT
8 T54 20VT/PK
9 T13 20DB/BK
10 K904 18DB/DG
11 K341 20PK/WT
12 K141 20TN/WT
13 T52 20RD/BK
14 T14 20LG/WT
C107 - LT. GRAY (TRANSMISSION HARNESS
SIDE)
CAV CIRCUIT
1 K399 18BR/GY
2 L1 20VT/BK
3 F20 20WT
4 T1 20LG/BK
5 T3 20VT
6 T42 20VT/WT
7 T41 20BR/YL
8 T54 20VT/PK
9 T13 20DB/BK
10 K904 18DB/DG
11 K341 20PK/WT
12 K141 20TN/WT
13 T52 20RD/BK
14 T14 20LG/WT
LH 8W-80 CONNECTOR PIN-OUTS 8W - 80 - 13
