Description N·m Ft. Lbs. In. Lbs.
Bolt, Solenoid/Pressure Switch Assy-to-
Valve Body
653
Bolt, Valve Body-to-Case 12 105
Bolt, Valve Body-to-Transfer Plate 5 45
Connector, Solenoid/Pressure Switch
Assembly
653
Fitting, Cooler Line 18 155
Nut, Output Shaft 271 200
Nut, Transfer Shaft Stake 271 200
Plug, Differential Drain 7 62
Plug, Differential Fill 47 35
Plug, Pressure Tap 6 53
Sensor, Input Speed-to-Case 27 20
Sensor, Output Speed-to-Case 27 20
Vent, Differential 11 100
Vent, Main Sump 11 100
SPECIAL TOOLS
42LE AUTOMATIC TRANSAXLE
Puller Press Extension C-293-3
Adapter Blocks C-293–48
Puller Press C-293–PA
Pressure Gauge (High) C-3293SP
Dial Indicator C-3339
Slide Hammer C-3752
LH TRANSAXLE 21 - 63
42LE AUTOMATIC TRANSAXLE (Continued)
