FLUID, TRANSMISSION & DIFFERENTIAL
Location Type Metric Capacity Standard Capacity
Transmission Sump MoparT ATF+4 Type 9602 9.29L 9.81 Qts.
Differential Sump MoparT Fuel Saving
75W-90 Petroleum-Based
Hypoid Gear Lube
0.95L 32 oz.
INPUT SHAFT
Description Metric Standard
End Play 0.12-0.63 mm 0.005-0.025 in.
OIL PUMP CLEARANCES
DESCRIPTION METRIC STANDARD
Outer Gear-to-Crescent 0.060-0.298 mm 0.0023-0.0117 in.
Inner Gear-to-Crescent 0.093-0.385 mm 0.0036-0.0151 in.
Outer Gear-to-Pocket 0.089-0.202 mm 0.0035-0.0079 in.
Outer Gear Side Clearance 0.020-0.046 mm 0.0008-0.0018 in.
Inner Gear Side Clearance 0.020-0.046 mm 0.0008-0.0018 in.
TRANSFER SYSTEM
Description Metric Standard
Sprocket Height Variance ± 0.457 mm ± 0.018 in.
TORQUE SPECIFICATIONS
Description N·m Ft. Lbs. In. Lbs.
Bolt, Converter-to-Driveplate 88 65
Bolt, Differential Assembly Partial 8 71
Bolt, Differential Case Cover 28 250
Bolt, Differential Ring Gear-to-Case 95 70
Bolt, Differential Vent Baffle 5 45
Bolt, Driveplate-to-Crankshaft 95 70
Bolt, End Cover-to-Case 28 250
Bolt, Fluid Filter-to-Valve Body 5 45
Bolt, L/R Clutch Retainer-to-Case 5 45
Bolt, Main Sump Vent 5 45
Bolt, Manual Valve Lever-to-Manual Valve 5 45
Bolt, Oil Pan-to-Case 23 17
Bolt, Oil Pump-to-Case 28 250
Bolt, Park Sprag Retainer 5 45
Bolt, Reaction Shaft Support Halves 28 250
Bolt, Snubber 5 45
21 - 62 TRANSAXLE LH
42LE AUTOMATIC TRANSAXLE (Continued)
