C312 - BLACK (REAR FASCIA SIDE)
CAV CIRCUIT
1 L7 18BK/YL
2 Z1 18BK
C313 (CONCORDE/DODGE/300M) - GRAY (TAIL
LAMP SIDE)
CAV CIRCUIT
1 L50 18WT/TN
2 L60 18LG/TN
3-
4 L7 18BK/YL
5 L1 18VT/BK
6 Z1 18BK
C313 (DODGE/300M) - GRAY (BODY SIDE)
CAV CIRCUIT
1 L50 16WT/TN
2 L60 16TN
3-
4 L7 18BK/YL
5 L1 20VT/BK
6 Z1 16BK
C313 (LTD/BUILT-UP-EXPORT) - (TAIL LAMPS
SIDE)
CAV CIRCUIT
1 L50 18WT/TN
2 L60 18LG/TN
3 L95 18DG/YL (BUILT-UP-EXPORT)
4 L7 18BK/YL
5 L1 18VT/BK (BUILT-UP-EXPORT)
6 Z1 18BK
8W - 80 - 30 8W-80 CONNECTOR PIN-OUTS LH
