CONNECTOR NAME/NUMBER COLOR LOCATION FIG.
C318 NAT Under Passenger Seat 13
C319 NAT Under Drivers Seat 15
C320 NAT Left Side Shelf Panel 20, 22
C321 (300M) Deck Lid 22
C322 BK Left B Pillar 16
C325 LG At Left C Pillar, Behind Sholder Belt Ancor 21
C360 BK At bottom of I/P Center Stack 12
Camshaft Position Sensor BK Front of Engine 5, 6
Center High Mounted Stop Lamp BK At Lamp N/S
Center Instrument Panel Speaker BK At Speaker 9
Cigar Lighter NAT Lower Center of Instrument Panel 9
Clockspring No. 1 NAT Rear of Clockspring 8
Clockspring No. 2 YL Rear of Clockspring 8
Clockspring No. 3 At Steering Wheel N/S
Coil On Plug No. 1 BK At Plug 5, 6
Coil On Plug No. 2 BK At Plug 5, 6
Coil On Plug No. 3 BK At Plug 5, 6
Coil On Plug No. 4 BK At Plug 5, 6
Coil On Plug No. 5 BK At Plug 5, 6
Coil On Plug No. 6 BK At Plug 5, 6
Combination Flasher BK Left Side Instrument Panel 8, 15
Compact Disc Changer BK At Rear of CD Changer N/S
Controller Anti-Lock Brake BK Left Fender Side Shield 3
Crankshaft Position Sensor BK Rear of Cyl Block 5, 6
Data Link Connector BK LT Side of Steering Column 8, 12
Daytime Running Lamp Module In Junction Block N/S
Decklid Release Solenoid/Ajar
Switch
BK At Decklid Latch 22
Decklid Release Switch BK Left Side of I/P 8
Door Lock Relay In Junction Block N/S
Door Unlock Relay In Junction Block N/S
Driver Airbag Squib YL At Steering Wheel N/S
Driver Door Courtesy Lamp BK Left Front Door 18
Driver Door Cylinder Lock Switch GY Left Front Door 17
Driver Door Lock Motor/Ajar Switch BK Left Front Door 17
Driver Door Unlock Relay In Junction Block N/S
Driver Heated Seat Back GN At Driver Seat N/S
Driver Heated Seat Cushion BK At Driver Seat N/S
Driver Heated Seat Switch RD At Driver Seat N/S
Driver Power Door Lock Switch NAT Left Front Door 18
Driver Power Mirror NAT Driver Door 17
Driver Power Mirror (Memory) WT Driver Door N/S
LH 8W-91 CONNECTOR/GROUND/SPLICE LOCATION 8W - 91 - 3
CONNECTOR/GROUND/SPLICE LOCATION (Continued)
