HEADREST
REMOVAL
REMOVAL
(1) Lower head restraint slightly.
(2) Insert a stiff wire into the hole on the right
hand side head restraint sleeve/guide and push to
release latch (Fig. 3).
(3) At the same time, press the button on the head
restraint sleeve/guide left hand side and pull upward
to release the head restraint.
(4) Remove head restraint from seat back.
REMOVAL - AIRBAG EQUIPPED
WARNING: DISCONNECT AND ISOLATE THE NEGA-
TIVE BATTERY CABLE REMOTE TERMINAL
BEFORE BEGINNING ANY FRONT SEAT REMOVAL
OR INSTALLATION PROCEDURE. THIS WILL DIS-
ABLE THE AIRBAG SYSTEM. FAILURE TO DISCON-
NECT THE BATTERY COULD RESULT IN
ACCIDENTAL AIRBAG DEPLOYMENT AND POSSI-
BLE PERSONAL INJURY.
WARNING: ONCE THE NEGATIVE CABLE IS DIS-
CONNECTED WAIT FOR 2 MINUTES BEFORE
REMOVING ANY AIRBAG SYSTEM COMPONENTS.
(1) Disconnect the remote negative battery cable.
(2) If fully extended, lower head restraint slightly.
(3) Insert a stiff wire into the hole on the right
hand side head restraint sleeve/guide and push to
release latch (Fig. 4).
(4) At the same time, press the button on the head
restraint sleeve/guide and pull upward to release the
head restraint.
(5) Remove head restraint from seat back.
INSTALLATION
INSTALLATION
(1) Place head restraint in position.
(2) Push head restraint down into the lock posi-
tion.
(3) Raise head restraint to ensure it locks at the
last stop.
INSTALLATION - AIRBAG EQUIPPED
(1) Place head restraint in position.
(2) Push head restraint down into the lock posi-
tion.
(3) Raise head restraint to ensure it locks at the
last stop.
(4) Connect the remote negative battery cable.
Fig. 3 HEAD RESTRAINT REMOVAL
1 - SLEEVE GUIDE
2 - BUTTON
3 - STIFF WIRE
Fig. 4 HEAD RESTRAINT REMOVAL
1 - SLEEVE GUIDE
2 - BUTTON
3 - STIFF WIRE
23 - 80 SEATS LH
