SA
VE LABEL TEMPLA
TE
T
o save the label template, select the
Save
icon:
SA
VE LABEL TEMPLA
TE WITH DIFFERENT NAME
T
o save the label template with a
dier
ent
name:
1.
Select the
Save as
icon:
1.
2.
Enter a
dier
ent
name for the label template.
2.
3.
Select
Save
.
3.
OPERA
TION
148
EPT077343 EN - Issue 1 - 11 November 2022
147
149
Table of Contents
Domino
2
Amendment Record
2
Preface Product Manual
3
FCC Notice
4
European EMC Statement
4
Intended Use
4
Software Credits
5
Table of Contents
6
Part 1 Health and Safety
10
Introduction
10
Warnings, Cautions and Notes
11
Symbols
11
Inks and Fluids Information
13
Storage
13
Fire Risk
14
Spillages and Disposal
14
Electro-Static Discharge
15
Product/Battery End of Life
16
USA State of California Battery Statement
16
Part 2 System Description
17
Introduction
17
General
17
Description
17
Overview
18
G50I Controller Overview
18
GP Print Head Overview
20
User Interface
21
Specification
22
Controller Specification
22
GP Print Head Specification
23
Printing Speed Table
24
Pre-Installed Fonts
25
Controller IO Socket Description
26
Maximum Label Width
28
User Interface Overview
29
Main Interface Tool Bar
29
Home Screen Print Information
32
Label Template Designer
35
Part 3 Installation
38
Unpacking
38
Location
38
Vertical Installation
39
Horizontal Installation
43
Anti Shock (Optional) Installation
47
Print Head Orientation
48
Side View
48
Front View
49
Print Head Connection
50
Ink Cartridge Installation
51
Controller Electrical Supply
53
Print Head Product Detect Sensor Calibration
55
External Device Connection
56
External Product Detect Sensor
56
External Shaft Encoder
58
Alarm Beacon
59
IO Connection
60
Print Head Settings
61
Print Quality
61
Alignment
62
System Settings
63
Encoder Input - Internal
63
Encoder Input - External
64
Print Trigger - Continuous
65
Print Trigger - Sensor
66
Bi-Direction
67
Auto Switch Channel
68
High Speed
68
Print Static Image
69
Skew Angle
69
Auto Jet (Nozzle Purge)
70
Realtime
71
Advanced Settings
72
Display
72
User Mode (Security)
73
Remote
78
High Quality
79
IO Signal
80
Backup and Restore
81
Common
82
Configuring Print Controls
83
VDC Settings
84
VDC (Variable Data Connection)
84
Rule
87
Monitor
90
Network Settings
91
IP Address
91
DNS Server Address
92
Control the Printer Via Web Browser
93
Power Save Settings
94
Monitor
94
Language Settings
95
Import Language
95
Export Language
96
Delete Language
96
Font Settings
97
Import Font
97
Delete Font
97
Part 4 Operation
98
Start up
98
Load a Label to Print
101
Start Printing
102
Stop Printing
102
Shut down
103
Design a Label Template
106
Add Objects to Label Template
107
Add a Text Object
107
Add a Counter Object
109
Add a Database Object
112
Add a Barcode Object
123
Add a Static Graphics Object
126
Add a Dynamic Graphics Object
128
Add a Clocks Object
137
Add a Shift Code Object
142
Add a Line Object
144
Setting Name
144
Add a Boxlot Object
145
Text Align
147
Remove Blank Line
147
If the Object Has more than 1 Line, Set the Alignment
147
Left Center Right
147
Remove Blank Lines from the Object
147
Remove Leading Spaces from the Object
147
Save Label Template
148
Save Label Template with Different Name
148
Edit Object Properties
149
Delete Label Template
149
Import Label Template
150
Export Label Template
151
Log
152
Export Log
153
Statistic Counters
154
Part 5 Maintenance & Troubleshooting
155
Error Description
155
Description
155
Print Quality Faults
156
Update Software/Firmware
157
Replace Ink Cartridge
158
Purge Blocked Cartridge Nozzles
161
Clean the Cartridge Nozzles
162
Clean the Print Head
165
Clean the Controller
168
