SPECIFICATION
Controller Specification
Item Details
Dimensions: Width: 155 mm
Height: 111.6 mm
Depth: 44.65 mm
Weight: 622 g
Operating Temperature: 5 °C to 50 °C
Operating Relative Humidity: 90% non condensing.
IP Rating N/A (Not usable in wet locations)
User Interface: 5 Inch Touch Screen
Message Memory: 4 GB
Maximum Number of Print
Heads:
1
Printable Characters: Windows True Type Fonts
Electrical Power Supply Adapter: Input: 100-240 V AC, 1.4 A, 50/60 Hz
Output: 24 V DC, 2.5 A, 60 W
Maximum Electrical Power
Consumption:
60 W
External Connections:
• External Sensor (Product Detect Sensor)•
• External Encoder (Shaft Encoder)•
•
Alarm Beacon
•
• RS485•
•
RJ45 (Ethernet)
•
•
USB
•
Maximum Print Speed: 76 m/min at 300x300 DPI
Maximum Print Height: 12.7 mm (0.5 Inch)
Maximum Altitude of Operation: 2000 m
Intended Environment: Indoors only
SYSTEM DESCRIPTION
22 EPT077343 EN - Issue 1 - 11 November 2022
