PRINT HEAD CONNECTION
WARNING Electricity. Risk of injury.
Turn o the equipment and disconnect the power supply before
disconnecting or making electrical connections.
When powered on, the controller contains live electrical components.
Physical contact with live electrical components can result in an electric
shock.
CAUTION Electricity. Risk of damage to equipment.
Turn o the equipment and disconnect the power supply before
disconnecting or making electrical connections.
When powered on, the equipment contains live electrical components.
An incorrect electrical connection can damage the equipment.
The image below shows how to connect the print head to the controller.
INSTALLATION
50 EPT077343 EN - Issue 1 - 11 November 2022
