GP Print Head Overview
# Name Description
1 Data Socket Connect the print head to the controller.
2 Purge Button Press to purge the print head nozzles.
3 Sensitivity Adjust the product detect sensor sensitivity.
4 Extended Socket Do not use.
5 Sensor LED Turns on when the product detect sensor is triggered.
6 Alarm LED Turns on if there is an error.
7 Run/Stop LED Turns on when printing.
SYSTEM DESCRIPTION
