# Name Description
4 USB Socket Connect:
• Keyboard•
•
Mouse
•
• Memory device for data transfer.•
5 Print Head Socket Connect the print head.
6 IO Socket Connect:
• External sensor (product detect sensor)•
•
External encoder (shaft encoder)
•
• Alarm beacon.•
7 Status LED Status:
• Stop (Red) - Turns on if the electrical power supply•
is connected and the controller has booted up.
• Alarm (Amber) - Turns on if there is an error.•
•
Run (Green) - Turns on when printing.
•
8 Fan Cooling for the controller. Do not block the fan vents.
SYSTEM DESCRIPTION
EPT077343 EN - Issue 1 - 11 November 2022 19
