Alignment
To view the print head alignment settings:
1.
From the Home screen, select the Settings icon:
1.
2.
The Alignment settings listed below are available:
2.
Setting Name Description
Forward oset (mm) Set the distance between the point where the product detect
sensor is triggered and the point where the print is made.
Disable sensor (mm) Set a distance to disable the product detect sensor after it
has been triggered.
The purpose of this setting is to prevent multiple prints on a
product.
Fixed length (mm)
Note This setting is used if the "Repeat Times"
setting is dierent from 0 with "Sensor Mode".
Set the distance between 2 repeat prints.
Reverse oset (mm)
Note This setting is used if "Bi-Direction" mode is
enabled. See Bi-Direction on page 67.
Set the distance for the second print, between the point
where the product detect sensor is triggered and the point
where the print is made.
INSTALLATION
62 EPT077343 EN - Issue 1 - 11 November 2022
