II-2-1-1 Details Page for LAN1
II-2-1-1 Details Page for LAN1
–
–
Ethernet TCP/IP and DHCP Setup
Ethernet TCP/IP and DHCP Setup
There are two configuration pages for LAN1, Ethernet TCP/IP and DHCP Setup (based on
IPv4) and IPv6 Setup. Click the tab for each type and refer to the following explanations for
detailed information.
Available settings are explained as follows:
Item Description
Network Configuration For NAT Usage,
IP Address - Type in private IP address for connecting to a
local private network (Default: 192.168.1.1).
Subnet Mask - Type in an address code that determines the
size of the network. (Default: 255.255.255.0/ 24)
RIP Protocol Control,
Disable - deactivate the RIP protocol. It will lead to a
stoppage of the exchange of routing information between
routers. (Default)
Enable – activate the RIP protocol.
DHCP Server
Configuration
DHCP stands for Dynamic Host Configuration Protocol. The
router by factory default acts a DHCP server for your
network so it automatically dispatches related IP settings to
any local user configured as a DHCP client. It is highly
recommended that you leave the router enabled as a DHCP
server if you do not have a DHCP server for your network.
If you want to use another DHCP server in the network other
than the Vigor Router’s, you can let Relay Agent help you to
redirect the DHCP request to the specified location.
Enable Server - Let the router assign IP address to every
host in the LAN.
Disable Server – Let you manually assign IP address to every
host in the LAN.
Enable Relay Agent –Specify which subnet that DHCP server
is located the relay agent should redirect the DHCP request
to.
DHCP Server IP Address – It is available when Enable
Relay Agent is checked. Set the IP address of the
Vigor2762 Series User’s Guide
