II-1-2 Internet Access
II-1-2 Internet Access
For the router supports multi-WAN function, the users can set different WAN settings (for
WAN1/WAN2/WAN3) for Internet Access. Due to different Physical Mode for WAN interface,
the Access Mode for these connections also varies. Refer to the following figures.
And,
And,
Available settings are explained as follows:
Item Description
Index Display the WAN interface.
Display Name It shows the name of the WAN1/WAN2/WAN3 that entered
in general setup.
Physical Mode It shows the physical connection for WAN1~2 (Ethernet)
/WAN3 (3G/4G USB Modem) according to the real network
connection.
Access Mode Use the drop down list to choose a proper access mode. The
details page of that mode will be popped up. If not, click
Vigor2762 Series User’s Guide
