Draytek Vigor2762 series User Manual

II-1-1-2 WAN2 (Ethernet)
II-1-1-2 WAN2 (Ethernet)
Ethernet is the Physical Mode for WAN2.
Available settings are explained as follows:
Item Description
Enable Choose Yes to invoke the settings for this WAN interface.
Choose No to disable the settings for this WAN interface.
Display Name Type the description for such WAN interface.
Physical Mode Display the physical mode of such WAN interface.
Physical Type You can change the physical type for WAN1/WAN2/WAN3/
WAN4 or choose Auto negotiation for determined by the
system.
Line Speed If you choose According to Line Speed as the Load
Balance Mode, please type the line speed for downloading
and uploading for such WAN interface. The unit is kbps.
VLAN Tag insertion Enable – Enable the function of VLAN with tag.
The router will add specific VLAN number to all packets on
the WAN while sending them out.
Please type the tag value and specify the priority for the
packets sending by WAN1.
Disable – Disable the function of VLAN with tag.
Tag value – Type the value as the VLAN ID number. The
range is form 0 to 4095.
Priority – Type the packet priority number for such VLAN.
The range is from 0 to 7.
Active Mode Choose Always On to make the WAN connection being
Vigor2762 Series User’s Guide
54
