Disable – TTL value will not be reduced. Then, when a
packet passes through Vigor router, it will not be cancelled.
That is, the client who sends out the packet will not be
blocked by ISP.
PPP/MP Setup PPP Authentication – Select PAP only or PAP or CHAP for
PPP.
Idle Timeout – Set the timeout for breaking down the
Internet after passing through the time without any action.
IP Address Assignment
Method (IPCP)
Usually ISP dynamically assigns IP address to you each time
you connect to it and request. In some case, your ISP
provides service to always assign you the same IP address
whenever you request. In this case, you can fill in this IP
address in the Fixed IP field. Please contact your ISP before
you want to use this function.
Fixed IP – Click Yes to use this function and type in a fixed
IP address in the box of Fixed IP Address.
Default MAC Address – You can use Default MAC Address or
specify another MAC address by typing on the boxes of MAC
Address for the router.
Specify a MAC Address – Type the MAC address for the
router manually.
After finishing all the settings here, please click OK to activate them.
II-1-2-4 Details Page for Static or Dynamic IP in Ethernet WAN
II-1-2-4 Details Page for Static or Dynamic IP in Ethernet WAN
For static IP mode, you usually receive a fixed public IP address or a public subnet, namely
multiple public IP addresses from your DSL or Cable ISP service providers. In most cases, a
Cable service provider will offer a fixed public IP, while a DSL service provider will offer a
public subnet. If you have a public subnet, you could assign an IP address or many IP address
to the WAN interface.
To use Static or Dynamic IP as the accessing protocol of the internet, please click the Static
or Dynamic IP tab. The following web page will be shown.
Vigor2762 Series User’s Guide
