II-5-7 Wake on LAN
II-5-7 Wake on LAN
A PC client on LAN can be woken up by the router it connects. When a user wants to wake
up a specified PC through the router, he/she must type correct MAC address of the specified
PC on this web page of Wake on LAN (WOL) of this router.
In addition, such PC must have installed a network card supporting WOL function. By the
way, WOL function must be set as “Enable” on the BIOS setting.
Available settings are explained as follows:
Item Description
Wake by If you choose to be woken by MAC Address, you have to
type the correct MAC address of the host in MAC Address
boxes.
IP Address The IP addresses that have been configured in
Firewall>>Bind IP to MAC will be shown in this drop down
list. Choose the IP address from the drop down list that
you want to wake up.
MAC Address Type any one of the MAC address of the bound PCs.
Wake Up Click this button to wake up the selected IP. See the
following figure. The result will be shown on the box.
Vigor2762 Series User’s Guide
