Draytek Vigor2762 series User Manual

II-1-3 Multi-PVC/VLAN
II-1-3 Multi-PVC/VLAN
This router allows you to create multi-PVC for different data transferring for using. Simply
go to WAN and select Multi-PVC/VLAN page.
General
General
The system allows you to set up to eight channels which are ready for choosing as the first
PVC line that will be used as multi-PVC.
Available settings are explained as follows:
Item Description
Channel Display the number of each channel.
Channels 1 and 2 are used by the Internet Access web user
interface and can not be configured here.
Channels 4 ~ 10 are configurable.
Enable Display whether the settings in this channel are enabled
(Yes) or not (No).
WAN Type Displays the physical medium that the channel will use.
VPI/VCI Display the value for VPI and VCI.
VLAN Tag Displays the VLAN tag value that will be used for the
packets traveling on this channel.
Port-based Bridge The network traffic flowing on each channel will be
identified by the system via their VLAN Tags. Channels using
the same WAN type may not configure the same VLAN tag
value.
Enable - Check this box to enable the port-based bridge
function on this channel.
P1 ~ P4 – Check the box(es) to build bridge connection on
LAN.
Vigor2762 Series User’s Guide
89
