V-1-2 Filter Setup
V-1-2 Filter Setup
Click Firewall and click Filter Setup to open the setup page.
To edit or add a filter, click on the set number to edit the individual set. The following page
will be shown. Each filter set contains up to 7 rules. Click on the rule number button to edit
each rule. Check Active to enable the filter rule.
Available settings are explained as follows:
Item Description
Rule Click a button numbered (1 ~ 7) to edit the filter rule. Click
the button will open Edit Filter Rule web page. For the
detailed information, refer to the following page.
Active Enable or disable the filter rule.
Comment Enter filter set comments/description. Maximum length is
23–character long.
Direction Display the direction of packet flow
Src IP Dst IP Display the source IP address and destination IP address of
the rule.
Vigor2762 Series User’s Guide
To Next Page
