Item Description
Service Type Display the protocol setting with source port and
destination port value.
Action Display the action taken when packets match the rule.
CSM Display the CSM profile name used by such rule.
Move Up/Down Use Up or Down link to move the order of the filter rules.
Next Filter Set Set the link to the next filter set to be executed after the
current filter run. Do not make a loop with many filter sets.
Wizard Mode Allow to configure frequently used settings of filter rule via
three setting pages
Advance Mode Allow to configure detailed settings of filter rule in one
page.
To use Wizard Mode, simple do the following steps:
1. Click the Wizard Mode radio button.
2. Click one of the indexe number linke (e.g., Index 2) to access into the following page.
Available settings are explained as follows:
Item Description
Comments Enter filter set comments/description. Maximum length is
14- character long.
Direction Set the direction of packet flow. It is for Data Filter only.
For the Call Filter, this setting is not available since Call
Filter is only applied to outgoing traffic.
Vigor2762 Series User’s Guide
