Available settings are explained as follows:
Item Description
Enable Choose Yes to invoke the settings for this WAN interface.
Choose No to disable the settings for this WAN interface.
Display Name Type the description for such interface.
Physical Mode Display the physical mode of such interface.
DSL Mode Specify the physical mode (VDSL or ADSL) for such router
manually.
DSL Modem Code Choose the correct DSL modem code for ensuring the
network connection.
If you have no idea about the selection, simply choose
Default or contact the dealer for assistance.
VLAN Tag insertion
(ADSL/VDSL)
Such feature is offered to the user with the environment
supporting IEEE_802.1ad. In which, service is used for
outer tag; customer is used for inner tag.
Enable – Enable the function of VLAN with tag.
The router will add specific VLAN number to all packets on
the WAN while sending them out.
Please type the tag value and specify the priority for the
packets sending by WAN1.
Disable – Disable the function of VLAN with tag.
Tag value – Type the value as the VLAN ID number. The
range is form 0 to 4095.
Priority – Type the packet priority number for such VLAN.
The range is from 0 to 7.
Vigor2762 Series User’s Guide
