in setting in the LAN-to-LAN Profile setup. This item is
optional and can be used only in IKE aggressive mode.
 Local Certificate – Select one of the profiles set in
Certificate Management>>Local Certificate.
IPsec Security Method - This group of fields is a must for
IPsec Tunnels and L2TP with IPsec Policy.
 Medium AH (Authentication Header) means data will
be authenticated, but not be encrypted. By default,
this option is active.
 High (ESP-Encapsulating Security Payload)- means
payload (data) will be encrypted and authenticated.
Select from below:
 DES without Authentication -Use DES encryption
algorithm and not apply any authentication scheme.
 DES with Authentication-Use DES encryption
algorithm and apply MD5 or SHA-1 authentication
algorithm.
 3DES without Authentication-Use triple DES
encryption algorithm and not apply any authentication
scheme.
 3DES with Authentication-Use triple DES encryption
algorithm and apply MD5 or SHA-1 authentication
algorithm.
 AES without Authentication-Use AES encryption
algorithm and not apply any authentication scheme.
 AES with Authentication-Use AES encryption
algorithm and apply MD5 or SHA-1 authentication
algorithm.
Advanced - Specify mode, proposal and key life of each IKE
phase, Gateway, etc.
The window of advance setup is shown as below:
IKE phase 1 mode -Select from Main mode and Aggressive
mode. The ultimate outcome is to exchange security
proposals to create a protected secure channel. Main mode
is more secure than Aggressive mode since more exchanges
are done in a secure channel to set up the IPsec session.
However, the Aggressive mode is faster. The default value
in Vigor router is Main mode.
 IKE phase 1 proposal-To propose the local available
authentication schemes and encryption algorithms to
the VPN peers, and get its feedback to find a match.
Two combinations are available for Aggressive mode
and nine for Main mode. We suggest you select the
combination that covers the most schemes.
 IKE phase 2 proposal-To propose the local available
algorithms to the VPN peers, and get its feedback to
find a match. Three combinations are available for
both modes. We suggest you select the combination
Vigor2762 Series User’s Guide
206
