Specific Limitation Start IP - Define the start IP address for limit bandwidth.
End IP - Define the end IP address for limit bandwidth.
Each /Shared - Select Each to make each IP within the
range of Start IP and End IP having the same speed defined
in TX limit and RX limit fields; select Shared to make all the
IPs within the range of Start IP and End IP share the speed
defined in TX limit and RX limit fields.
TX limit - Define the limitation for the speed of the
upstream. If you do not set the limit in this field, the
system will use the default speed for the specific limitation
you set for each index.
RX limit - Define the limitation for the speed of the
downstream. If you do not set the limit in this field, the
system will use the default speed for the specific limitation
you set for each index.
Add - Add the specific speed limitation onto the list above.
Edit - Allow you to edit the settings for the selected
limitation.
Delete - Remove the selected settings existing on the
limitation list.
Allow auto adjustment to
assign available …
Check this box to make the best utilization of available
bandwidth.
Smart Bandwidth Limit Check this box to have the bandwidth limit determined by
the system automatically.
TX limit - Define the limitation for the speed of the
upstream. If you do not set the limit in this field, the
system will use the default speed for the specific limitation
you set for each index.
RX limit - Define the limitation for the speed of the
downstream. If you do not set the limit in this field, the
system will use the default speed for the specific limitation
you set for each index.
Time Schedule Index (1-15) in Schedule Setup - You can type in four sets
of time schedule for your request. All the schedules can be
set previously in Application >> Schedule web page and
you can use the number that you have set in that web page.
Vigor2762 Series User’s Guide
