Duplo DC-646 - WIZARD

99
2
PC Controller Setting
4
Programming a JOB for DC-646 Via Computer (PC Controller)
WIZARD
The DC-646 can save up to 250 patterns of JOBs.
This section describes the procedure for
programming a JOB in the
Wizard mode
with preview
display. Following items should be entered to program a JOB.
Slot 2, 3, 4
Select an optional module for the JOB when necessary.
JOB No.
Select a JOB number to be programmed. (1–250)
JOB Name
Enter a name to the JOB to be programmed.
Paper Size
Enter the size of a document.
Finished Size
Specify the size of fi nished cards/processed documents.
Cards per document
Specify how many cards are to be aligned in a crosswise and in a lengthwise direction.
Trim
Specify the position of the fi rst cut and right margin slit.
Gutter Slits (Distance between fi nished documents (left/right))
When aligning two or three cards in a crosswise direction, it is possible to have a gutter slit
between each card.
Gutter Cuts (Distance between fi nished documents (top/bottom))
When aligning two or more cards in a lengthwise direction, it is possible to have a gutter cut
between each card.
Crease
Specify the position of the crease on the cards.
Up to 20 creases can be set on a document.
Inch>>
mm
The values entered in inches are converted to
ones in millimeters automatically.
Air Knife
Air is blown out to loosen documents, preventing a double feed.
Fan
Register
Document skewing in the
feeding area
is corrected.
