Duplo DC-646 User Manual

16
Preparation Before Use
After hanging the module on the
module hanger
,
check again that the both edges are hung on the
module hanger
.
Do not move the main unit with the module hung
on the
module hanger
. Doing so may drop the
module.
You can hang the edges of the top plate of the unused module on the
module hanger
. Two
module hangers
(upper and lower) are equipped with the main unit and enable you to hang
two modules.
Hang the module on the
module hanger
so that
both edges of the top plate of the module and the
module hanger
are parallel.
IMPORTANT
IMPORTANT
When hanging the module on the
module
hanger
or unhanging it from the
module hanger
,
be careful not to bring the module in contact with
the USB cable. Doing so may damage the USB
terminal/port.
IMPORTANT
Module Hanger
When hanging the module on the
module
hanger
, make sure that the both edges are
aligned with the
module hanger
.
Module
Module
hanger
Edge of
top plate
Module
Edge of top plate
Module
Edge of
top plate
Edge of top plate
Module
USB cable
