2
177
Troubleshooting
When a Document Jam Has Occurred
5
Remove the jammed document in the CCD area.
Press the STOP key to clear the error.
The machine is reset and the error message is
cleared.
Close the
top cover 2
and the
top cover 3
.
J5 MSM/SLOT2
A document jam has occurred in the
margin slitter module
or
slot 2.
Follow the procedure below to remove the jammed document.
Follow the procedure below as well if
SLOT#-* LOCK
,
MSM-*
LOCK
, or
SLOT# UPPER LOCK
appears.
REFERENCE
Remove document
from MSM/SLOT2
to clear
J5-*
