60
Function Setting
Function Setting 1
Use the CURSOR (Up/Down) key to select
Settings1
and press
the SET key.
Air Knife
Compressed air is blown out from the front of documents to
loosen them, preventing a double feed.
Use the CURSOR (Right/Left) key to select
ON
or
OFF
and press
the CURSOR (Down) key.
When using light weight documents, select
OFF
.
Side blow fan (Option: ASIA, TAIWAN)
Air is blown out to the edge of the document to easily separate
documents when they are fed.
Use the CURSOR (Right/Left) key to select
MAX
,
MID
,
MIN
or
OFF
and press the CURSOR (Down) key.
Fan reg
Document skewing in the
feeding area
is corrected.
Use the CURSOR (Right/Left) key to select
MAX
,
MID
,
MIN
or
OFF
and press the CURSOR (Down) key.
*/**
Fan reg
Settings1
MAX MID MIN OFF
*/**
MAX MID MIN OFF
Settings1
Side blow fan
Make sure that the standby screen is displayed on the LCD
panel. Press the F key.
(
REFERENCE
Select
MIN
or
OFF
for light weight documents to prevent a
document jam.
Select menu
Retrieve JOB
Enter JOB
Settings1
*/**
Settings1
Air knife
ON OFF
Read REG mark
Set the number of documents on which REG mark is read.
Use the CURSOR (Right/Left) key to select
ALL
,
Only rst sht
,
Every**sht
,
**.*mm or more
, or
OFF
and press the CURSOR
(Down) key.
*/**
Settings1
Read REG mark
ALL
