Duplo DC-646 User Manual

2
Specifi cations
217
Specifi cations
7
Model name DC-646
Standard functions • 250 jobs can be stored in the machine. (Job fi les can also be stored
in the via PC Controller.)
• Test feed
• PDF template generator
• Feed skew adjustment
• Air knife
• Ultrasonic double feed detection
• Emergency stop
• Automatic job setup by reading Barcode
• Image drift compensation by reading REG mark
• End mark detection
• Reject
(Document length: 670.0 mm or shorter)
• Pause feeding
• Job lock
• Batch separation
(Not available when IFS connected.)
• PC Controller (USB connection: B-type connector)
Compatible OS:
Windows 7 (32bit/64bit)
Windows 8.1 (32bit/64bit)
Windows 10 (32bit/64bit)
Optional devices Rotary Tool Module
Cross Tool Module
Optional Slitter Module
PC Arm
Side Air
Power supply 100 VAC±10%, 50/60 Hz
115 VAC, 60 Hz
230 VAC, 50/60 Hz
Power consumption Consumption Standby
Current Power Current Power
100 V 4.7 A 430 W 0.7 A 66 W
115 V 4.0 A 420 W 0.74 A 70 W
230 V 1.9 A 400 W 0.54 A 73 W
Dimensions
●
DC-646 115V, DC-646 230V
In use (standard): 2310(W)×1005(D)×1110(H) mm
In use (max paper): 2510(W)×1005(D)×1110(H) mm
When stored: 1650(W)×1005(D)×1110(H) mm
When packed: 1760(W)×880(D)×1335(H) mm
●
DC-646 100V, DC-646 230V (ASIA), DC-646 115V (TAIWAN)
In use (standard): 2310(W)×765(D)×1110(H) mm
In use (max paper): 2510(W)×765(D)×1110(H) mm
When stored: 1650(W)×765(D)×1110(H) mm
When packed: 1760(W)×880(D)×1335(H) mm
Weight Net weight Gross weight
DC-646 230V 280 kg 345 kg
DC-646 115V 280 kg 345 kg
DC-646 100V
DC-646 230V (ASIA)
DC-646 115V (TAIWAN)
275 kg 340 kg
