Dynapac CC424HF - Edge Cutter (Optional) - Lubrication

Maintenance - 250h
ICC424HF-CN1EN2.pdf2012-11-23
Edge cutter (Optional)
- Lubrication
Figure. Two grease points for
lubricating the edge cutter
2
1
Refer to the operation section for information on
how to operate the edge cutter.
Refer to the operation section for information on
how to operate the edge cutter.
Grease the two points as shown in the figure.
Grease should always be used for lubrication, see the
lubricant specifications.
Grease all bearing points with five strokes of a
hand-operated grease gun.
91
