Dynapac CC424HF - Every 50 Hours of Operation (Weekly); Every 250 Hours of Operation (Monthly); Every 500 Hours of Operation (Every Three Months)

Maintenance - Maintenance schedule
ICC424HF-CN1EN2.pdf2012-11-23
Every 50 hours of operation (Weekly)
Refer to the contents to find the page number of the
sections referred to !
Pos.
in fig
Action CommentPos.
in fig
Action Comment
10 Inspect/clean the filter element in the air cleaner Replace as required10 Inspect/clean the filter element in the air cleaner Replace as required
15 Check the oil level in the drum gears15 Check the oil level in the drum gears
3 Draining the fuel prefilter3 Draining the fuel prefilter
22,23 Inspect the air conditioning Optional22,23 Inspect the air conditioning Optional
24 Inspect/lubricate the edge cutter Optional24 Inspect/lubricate the edge cutter Optional
Every 250 hours of operation (Monthly)
Refer to the contents to find the page number of the
sections referred to !
Pos.
in fig
Action CommentPos.
in fig
Action Comment
8 Clean the hydraulic fluid cooler/water cooler Or when required8 Clean the hydraulic fluid cooler/water cooler Or when required
22,23 Check the AC Optional22,23 Check the AC Optional
20 Check the batteries condition.20 Check the batteries condition.
Every 500 hours of operation (Every three
months)
Refer to the contents to find the page number of the
sections referred to !
Pos.
in fig
Action CommentPos.
in fig
Action Comment
1,2 Change the diesel engine oil and oil filter *) Refer to the engine manual1,2 Change the diesel engine oil and oil filter *) Refer to the engine manual
3 Change the engine fuel filter Refer to the engine manual3 Change the engine fuel filter Refer to the engine manual
3 Change the engine pre-filter3 Change the engine pre-filter
16 Check the oil level in the drums16 Check the oil level in the drums
21 Lubricate the pivot bearings Optional21 Lubricate the pivot bearings Optional
19 Check rubber elements and bolted joints19 Check rubber elements and bolted joints
7 Check the hydraulic reservoir cover/breather7 Check the hydraulic reservoir cover/breather
18 Grease the chair bearing18 Grease the chair bearing
*) Only applicable for correct fuel quality, otherwise change every 250 hours.*) Only applicable for correct fuel quality, otherwise change every 250 hours.
75
