Operation
ICC424HF-CN1EN2.pdf2012-11-23
Parking
Chocking the drums
Fig. Positioning
1. Chocks
1
1
Never disembark from the machine when the
diesel engine is running, unless the parking brake
is activated.
Never disembark from the machine when the
diesel engine is running, unless the parking brake
is activated.
Make sure that the roller is parked in a safe place
with respect to other road users. Chock the drums
if the roller is parked on sloping ground.
Make sure that the roller is parked in a safe place
with respect to other road users. Chock the drums
if the roller is parked on sloping ground.
Keep in mind that there is a risk of freezing during
the winter. Drain the water tanks, pumps and
water lines.
Fill antifreeze in the engine cooling system and
the washer fluid reservoir in the cab. Also see
maintenance instructions.
Keep in mind that there is a risk of freezing during
the winter. Drain the water tanks, pumps and
water lines.
Fill antifreeze in the engine cooling system and
the washer fluid reservoir in the cab. Also see
maintenance instructions.
Master switch
1
Figure. Engine door, left
1. Battery disconnector
Before leaving the roller for the day, switch the master
switch (1) to the disconnected position and remove the
handle.
Before switching off the battery isolation switch,
wait for at least 30 seconds after the ignition lock
has been switched off, in order to avoid the
engine's electronic control unit (ECU) sustaining
damage.
Before switching off the battery isolation switch,
wait for at least 30 seconds after the ignition lock
has been switched off, in order to avoid the
engine's electronic control unit (ECU) sustaining
damage.
This will prevent battery discharging and will also
make it difficult for unauthorized persons to start and
operate the machine. Lock the service doors/covers.
57
