Operation
ICC424HF-CN1EN2.pdf 2012-11-23
Starting
Starting the engine
2
1
Fig. Control panel
1. F/R lever
2. Rpm switch
3. Ignition key
3
Make sure that the emergency stop is OFF and the
parking brake ON.
Set the forward/reverse lever (1) in neutral position,
and set the speed selector (2) in the idling position
(LO).
The diesel engine cannot be started in any other
position of the controls.
Turn the ignition key (3) right to position I and then
engage the starter by turning it full right. Release back
to I as soon as the engine starts.
Do not run the starter motor for too long (max. 30
seconds). If the engine will not start, wait a
minute before trying again.
Do not run the starter motor for too long (max. 30
seconds). If the engine will not start, wait a
minute before trying again.
At the start of the diesel engine when the ambient
temperature is below +10 ° C (50 ° F), it must be
warmed up at idle (low speed) until the hydraulic oil
temperature exceeds +10 ° C (50 ° F).
Ensue that there is good ventilation (air extraction)
if the engine is run indoors. Risk of carbon
monoxide poisoning.
Ensue that there is good ventilation (air extraction)
if the engine is run indoors. Risk of carbon
monoxide poisoning.
Figure. Display - Status image
Check during warming up of the engine that fuel and
water levels are shown correctly and that the voltage
is at least 24V.
48
