Dynapac CC424HF - Maintenance - Maintenance Schedule; Service and Maintenance Points

Maintenance - Maintenance schedule
ICC424HF-CN1EN2.pdf2012-11-23
Maintenance - Maintenance schedule
Service and maintenance points
Fig. Service and maintenance points
1
2
3
14
4
5
3
6, 7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
1. Engine oil 9. Coolant 17. Steering joint1. Engine oil 9. Coolant 17. Steering joint
2. Oil filter 10. Air cleaner 18. Seat bearing2. Oil filter 10. Air cleaner 18. Seat bearing
3. Fuel filter 11. Refueling point 19. Rubber element3. Fuel filter 11. Refueling point 19. Rubber element
4. Hydraulic filter 12. Scrapers 20. Battery4. Hydraulic filter 12. Scrapers 20. Battery
5. Hydraulic fluid level 13. Water tank(s), filling 21. Pivot bearing5. Hydraulic fluid level 13. Water tank(s), filling 21. Pivot bearing
6. Hydraulic fluid, filling 14. Watering system 22. Cab, air filter6. Hydraulic fluid, filling 14. Watering system 22. Cab, air filter
7. Hydraulic tank cap 15. Drum gear 23. Cab, AC7. Hydraulic tank cap 15. Drum gear 23. Cab, AC
8. Hydraulic fluid cooler 16. Drum oil 24. Edge cutter8. Hydraulic fluid cooler 16. Drum oil 24. Edge cutter
73
