Dynapac CC424HF - Working Capacity; General

Technical specifications
ICC424HF-CN1EN2.pdf 2012-11-23
Working capacity
Compaction dataCompaction data
Static linear load, front 30,9 kg/cm 173 pliStatic linear load, front 30,9 kg/cm 173 pli
Static linear load, rear 29,8 kg/cm 167 pliStatic linear load, rear 29,8 kg/cm 167 pli
Amplitude, high 0,8 mm 0.031 inAmplitude, high 0,8 mm 0.031 in
Amplitud, low 0,3 mm 0.012 inAmplitud, low 0,3 mm 0.012 in
Vibration frequency, high
amplitude
51 Hz 3060 vpmVibration frequency, high
amplitude
51 Hz 3060 vpm
Vibration frequency, low
amplitude
67 Hz 4020 vpmVibration frequency, low
amplitude
67 Hz 4020 vpm
Centrifugal force, high
amplitude
142 kN 31 950 lbfCentrifugal force, high
amplitude
142 kN 31 950 lbf
Centrifugal force, low
amplitude
93 kN 20 925 lbfCentrifugal force, low
amplitude
93 kN 20 925 lbf
PropulsionPropulsion
Speed range 0-12 km/h 0-7.5 mph
Speed range 0-12 km/h 0-7.5 mph
Climbing capacity (theoretical) 45 %Climbing capacity (theoretical) 45 %
General
EngineEngine
Manufacturer/Model Cummins QSB 4.5Manufacturer/Model Cummins QSB 4.5
Power (SAE J1995) 82/93 kW 110/125 hpPower (SAE J1995) 82/93 kW 110/125 hp
Engine speed 2200 rpmEngine speed 2200 rpm
Electrical systemElectrical system
Battery 24V (2x12V 74Ah)Battery 24V (2x12V 74Ah)
Alternator 24V 45AAlternator 24V 45A
Fuses See the Electrical system section - fusesFuses See the Electrical system section - fuses
Bulbs (if mounted) Watt SocketBulbs (if mounted) Watt Socket
Drive lights, front 75/70 P43t (H4)Drive lights, front 75/70 P43t (H4)
Direction lights, front 21 BA15sDirection lights, front 21 BA15s
Side lights 5 SV8,5Side lights 5 SV8,5
Brake-Position lights 21/5 BAY15dBrake-Position lights 21/5 BAY15d
16
