Maintenance - 500h
ICC424HF-CN1EN2.pdf2012-11-23
Hydraulic reservoir cap - Check
Figure. Rear frame front left side
1. Hydraulic reservoir cap
1
Turn up the machine so that the tank cap is accessible
from the left side of the machine.
Unscrew and make sure that the reservoir cap is not
clogged. Air must have unobstructed passage through
the cap in both directions.
If passage in either direction is blocked, clean the filter
with a little diesel oil and blow through with
compressed air until the block is removed, or replace
the cap with a new one.
Wear protective goggles when working with
compressed air.
Wear protective goggles when working with
compressed air.
97
