Dynapac CC424HF - Maintenance Symbols

Maintenance - Lubricants and symbols
ICC424HF-CN1EN2.pdf 2012-11-23
DYNAPAC/AtlasCopcoDYNAPAC/AtlasCopco
GREASE Shell Retinax LX2 or
equivalent.
Dynapac Roller Grease
(0.4kg),
P/N 4812030095
GREASE Shell Retinax LX2 or
equivalent.
Dynapac Roller Grease
(0.4kg),
P/N 4812030095
FUEL See engine manual. - -FUEL See engine manual. - -
TRANSMISSION OIL Air temperature -15°C - +40°C
(5°F-104°F)
Shell Spirax S3 AX
80W/90, API GL-5 or
equivalent
Dynapac Gear oil 300,
P/N 4812030756 (5 liters),
P/N 4812030117 (20 liters),
P/N 4812031574 (209
liters)
TRANSMISSION OIL Air temperature -15°C - +40°C
(5°F-104°F)
Shell Spirax S3 AX
80W/90, API GL-5 or
equivalent
Dynapac Gear oil 300,
P/N 4812030756 (5 liters),
P/N 4812030117 (20 liters),
P/N 4812031574 (209
liters)
Air temperature 0°C (32°F) -
above +40°C (104°F)
Shell Spirax S3 AX
85W/140, API GL-5 or
equivalent.
Air temperature 0°C (32°F) -
above +40°C (104°F)
Shell Spirax S3 AX
85W/140, API GL-5 or
equivalent.
COOLANT Anti-freeze protection down to
about -37°C (-34.6°F)
GlycoShell/Carcoolant
774C or equivalent,
(mixed 50/50 with water)
COOLANT Anti-freeze protection down to
about -37°C (-34.6°F)
GlycoShell/Carcoolant
774C or equivalent,
(mixed 50/50 with water)
Maintenance symbols
Engine, oil level Air filterEngine, oil level Air filter
Engine, oil filter BatteryEngine, oil filter Battery
Hydraulic reservoir, level SprinklerHydraulic reservoir, level Sprinkler
Hydraulic fluid, filter Sprinkler waterHydraulic fluid, filter Sprinkler water
Drum, oil level RecyclingDrum, oil level Recycling
Lubricating oil Fuel filterLubricating oil Fuel filter
Coolant level Pump gear, oil levelCoolant level Pump gear, oil level
Air pressure Sprinkler, tiresAir pressure Sprinkler, tires
72
