Machine description
ICC424HF-CN1EN2.pdf 2012-11-23
Explanation of 17PIN serial number
100 00123 V 0 A 123456100 00123 V 0 A 123456
A B C D E FA B C D E F
A= Manufacturer
B= Family/Model
C= Check letter
D= No coding
E= Production unit
F= Serial number
Engine plates
1
Fig. Engine
1. Type plate
The engine plate (1) is affixed to the left side of the
engine under the injection pump. Remove the metal
cover at the top on the left of the engine compartment
to access the plate.
The plate specifies the type of engine, its serial
number and the engine specification. Please specify
the engine serial number when ordering spares. Refer
also to the engine manual.
20
