Technical specifications
ICC424HF-CN1EN2.pdf2012-11-23
Bulbs (if mounted) Watt SocketBulbs (if mounted) Watt Socket
Direction lights, rear 21 BA15sDirection lights, rear 21 BA15s
License plate light 5 SV8,5License plate light 5 SV8,5
Working lights 70 PK22s (H3)Working lights 70 PK22s (H3)
35 Xenon35 Xenon
Cab lights 10 SV8,5Cab lights 10 SV8,5
Hydraulic system
Opening pressure MPa PsiOpening pressure MPa Psi
Drive system 40 5 800Drive system 40 5 800
Supply system 2.5 365Supply system 2.5 365
Vibration system 33 4 800Vibration system 33 4 800
Control systems 20 2 900Control systems 20 2 900
Brake release 1.8 260Brake release 1.8 260
Automatic Climate Control (ACC) (Optional)
The system described in this manual is an AC/ACC
type (Automatic Climate Control), i.e. a system that
maintains the set temperature in the cab, provided
windows and doors are kept closed.
Coolant designation: HFC-R134:A
Coolant weight when full: 1350 gram (2.98 lbs)
17
