Dynapac CC424HF - Operating Instructions - Summary

Operating instructions - Summary
ICC424HF-CN1EN2.pdf2012-11-23
Operating instructions - Summary
1. Follow the SAFETY INSTRUCTIONS specified in the Safety Manual.1. Follow the SAFETY INSTRUCTIONS specified in the Safety Manual.
2. Make sure that all instructions in the MAINTENANCE section are followed.2. Make sure that all instructions in the MAINTENANCE section are followed.
3. Turn the master switch to the ON position.3. Turn the master switch to the ON position.
4. Move the forward/reverse lever to the NEUTRAL position. Sit down in the seat.4. Move the forward/reverse lever to the NEUTRAL position. Sit down in the seat.
5. Engage the parking brake.5. Engage the parking brake.
6. Disengage the emergency stop. The roller is always starting in transportation
mode.
6. Disengage the emergency stop. The roller is always starting in transportation
mode.
7. Set the engine revs control button in position idle.7. Set the engine revs control button in position idle.
8. Start the engine and allow it to warm up.8. Start the engine and allow it to warm up.
9. Set the engine revs control button in position working speed.9. Set the engine revs control button in position working speed.
10. Disengage the parking brake.10. Disengage the parking brake.
11. Drive the roller. Operate the F/R lever with care.11. Drive the roller. Operate the F/R lever with care.
12. Test the brakes. Remember that the braking distance will be longer if the
hydraulic fluid is cold.
12. Test the brakes. Remember that the braking distance will be longer if the
hydraulic fluid is cold.
13. Set the transportation/working mode button in position working mode.13. Set the transportation/working mode button in position working mode.
14. Use vibration only when the roller is in motion.14. Use vibration only when the roller is in motion.
15. Check that the drums are thoroughly watered when watering is required.15. Check that the drums are thoroughly watered when watering is required.
16. IN AN EMERGENCY:
- Press the EMERGENCY STOP.
- Hold the steering wheel firmly.
- Brace yourself for a sudden stop.
16. IN AN EMERGENCY:
- Press the EMERGENCY STOP.
- Hold the steering wheel firmly.
- Brace yourself for a sudden stop.
17. When parking:
- Activate the parking brake.
- Switch off the engine and block the drums if the roller is on an inclined surface.
17. When parking:
- Activate the parking brake.
- Switch off the engine and block the drums if the roller is on an inclined surface.
18. When lifting: - Refer to the relevant section in the Instruction Manual.18. When lifting: - Refer to the relevant section in the Instruction Manual.
19. When towing: - Refer to the relevant section in the Instruction Manual.19. When towing: - Refer to the relevant section in the Instruction Manual.
20. When transporting: - Refer to the relevant section in the Instruction Manual.20. When transporting: - Refer to the relevant section in the Instruction Manual.
67
