Maintenance, 10h
ICC424HF-CN1EN2.pdf2012-11-23
2
3
Figure. Scraper setting
1. Retaining unit
2. Adjusting screw
3. Lock nut
The adjusting screw (2) is adjusted until the scraper
blade has a gap of approx. 1 mm (0.04 in) to the roller,
or lies loosely on the roller, along its entire length.
Tighten the lock nut (3).
